TAPIO 160 STROKE HARVESTING HEAD

Product menu

Technical specification

Length x width x height

  1030 x 550 x 630 mm

Weight

  215 kg

Electric system

  12/24 Vdc
Saw blade  12" 1.6 mm
Saw chain  .404" 1.6 mm
Pump/pressure 1500r/min  40-60 l/min 160 bar
Stroke length  500 mm
Stroke speed

 0.75 m / sec
Stroke power 12.86 kN
Maximum cutting diameter  250 mm
Maximum delimbing diameter  200 mm
Harvester output  15 kW





The following standard equipment are included in the delivery of Tapio 160 harvesting head:

  • Siemens Minilogo control system
  • Siemens Logo TD display
  • Logo TD display rack
  • 2 push button boxes, ready-connected to Siemens Minilogo
  • Push button box holder          2 pcs
  • 17x0,75 boom cable from Siemens MiniLogo unit to harvesting head
  • Connectors to boom cable 2+2 pcs
  • Covers to connectors 1+1 pcs
  • Saw blade .404"-1.6 12"
  • Saw chain .404"-1.6 48
  • Siemens MiniLogo instructions
  • Tapio 160 manual

Load brochure

TAPIO_160_Harvester_EN



Additional equipment:
Length measuring wheel



Basic machine options:

Agricultural tractors

Small forwarders

Small harvester units

Excavators of 3-6 tons





Get interested?

Don’t hesitate to contact us if you want further information or an offer!
